Preamplificator Phono Lindemann Limetree Phono Stage II

Descriere

Lindemann Audio Limetree MM/MC Phono II Stage

The new Limetree PHONO II from Lindemann Audio takes the highly-rated and awarded Limetree PHONO and further improves the internal circuitry for improved performance, especially when connected to an MC pickup. An added benefit for MC users is the customisable load impedance settings with the following values; 50R, 66R, 80R, 100R, 200R & 400R.

The Limetree PHONO II is Lindemann’s statement for all vinyl friends. A high-grade preamp for your pickup cartridge. Using the latest technologies and parts they reanimated a circuit design from the tube amp era. The result is absolutely worth listening to! Look forward to an exceptional sound experience!

The Limetree PHONO II has two discrete input stages which are perfectly tuned for the respective pickup type. This ensures maximum sound quality with MM and MC cartridges. Installation is as easy as 1-2-3: simply plugin and you’re ready to go. Only for MC there is a variable setting of the input impedance between 50 and 400 ohms. The measured values of the PHONO are exceptionally good all the way. Noise and distortion figures are close to the resolution limit.

To put it briefly: sound quality and technology of this amplifier play in a class of their own. Rediscover your LPs!

Features

The Limetree PHONO II falls back on a circuit design from the classic tube amp era. But this concept is a completely new reinterpretation using the latest technologies and components.

The dual-stage circuitry with a passive RIAA equalization network uses the best J-FET amplifiers, which are currently available, and ultra precision resistors and capacitors from Japan.

The purely passive equalization has a significant advantage: the distortions in the bass range are much lower than with the usually applied circuits.

For a power supply, Lindemann use a “medical grade“ wall plug transformer which ensures a particularly good isolation from line disturbances. Together with the elaborated onboard filtering and special voltage regulators, they were able to realize an exceptionally low-noise power supply with a ripple voltage below 10 µV.

Specification

• Measurement conditions: 22 °C, 230 V mains voltage, Audio Precision AP272
• Power consumption: 0.1 W standby, 0.8 W MM, 0.6 W MC
• Dimensions (W x H x D): 107 x 40 x 130 mm (4.2 x 1.6 x 5.1 in)
• Weight: 295 g (10.4 oz)
• Gain MM: 40 dB
• Gain MC: 66 dB
• Equalization: RIAA curve, overall deviation + 0 dB, – 0.5 dB
• Distortions: <0.001 % (at 0.5 V output)
• S/N ratio MM: >82 dBV (A-weighted, 600 ohms termination)
• S/N ratio MC: >78 dBV (A-weighted, 10 ohms termination)

About Lindemann Audio

Lindemann Audio is a renowned company with a rich history spanning over 25 years in designing and manufacturing loudspeakers, amplifiers, and digital sources. Their exceptional product range includes the popular Lindemann Limetree Bridge II Network Adaptor from the Limetree series.

With a strong philosophy rooted in its extensive experience, Lindemann Audio employs advanced design tools and precise measuring methods to develop its products. They combine the latest cutting-edge technologies with a commitment to achieving the best possible sound quality. Their meticulous attention to detail, careful circuit optimisation, and selection of top-grade components form the foundation of their genuine high-end offerings. Lindemann Audio achieves real progress in sound quality through a deep understanding of sound influences and consistent implementation in circuit design.

Passionate and experienced engineers in Germany lead the development of Lindemann Audio’s products, which are exclusively manufactured by ISO-certified firms across Europe. Each device undergoes a thorough final inspection before packaging and shipping, ensuring uncompromising quality that meets the high demands of its customers.

Lindemann Audio’s unwavering dedication to music and well-engineered technology is evident in its products, which consistently deliver impressive performance. Following Albert Einstein’s famous quote, they strive to make everything simple without compromising quality.

With a history marked by groundbreaking circuitry ideas and a commitment to embracing new trends and technologies, Lindemann Audio continues to push the boundaries of audio innovation. Their legacy includes achievements such as the first amplifier with ultra-fast current feedback, the first CD player with re-sampling, and the first German SACD player. Many of these pioneering products still bring joy to enthusiastic customers’ homes today.

Choose Lindemann Audio for an unparalleled audio experience where passion for music and cutting-edge technology harmoniously blend to create compelling products.
